SAMKOON SK-102QT HMI 10.2"

Structural Specifications for the SK-102QT:

• Dimensions:
  • Outer Dimensions: 273×211×44mm
  • Mounting Hole Dimensions: 259×201mm
• Weight: 1050g
• Casing Material: ABS+PC engineering plastic
• Display:
  • Display Size: 10.2″ (16:9)
  • Resolution (Pixels): 1024 × 600
  • Touch Panel: 4-wire high-precision touchpad
  • Display Colors: 16.7 million
  • Backlight Module: LED
  • Contrast Ratio: 400:1
  • Brightness (cd/m²): 450
• Product Features/Certifications:
  • Memory: 128MB FLASH + 128MB DDR3
  • CPU: Cortex A7 1GHz, Dual-core
  • Voltage Endurance Test: 1000V AC, 1 minute
  • Electrostatic Test: 4 levels ±8kV
  • FCC Compatibility: Complies with FCC, Class A
  • CE Certification: Complies with EN55032 and EN55035 standards
  • Protection Level: IP65 (Front Panel)
• Power/Interfaces:
  • Power Supply: (DC12~24V) ±15%
  • Power Consumption: 7W
  • Serial Interfaces: COM1 (RS232), COM2 (RS485/422), COM3 (RS485)
  • USB Download Port: Yes
  • USB Port: Yes
  • SD Card Slot: No
  • Ethernet Port: No
  • CAN Interface: No
• Network Connectivity:
  • WiFi: No
  • 3G: No
  • Ethernet: No
  • 4G: No
• Environmental Conditions:
  • Operating Temperature: -20°C to 55°C (non-freezing)
  • Operating Humidity: 5% to 95% RH (non-condensing)
  • Vibration Resistance: 10~25Hz (XYZ direction, 2G for 30 minutes)
• Programming Software: SKTOOL 7.0
